PERMETER - Double-walled stainless steel chimney system

Schiedel PERMETER

Double-walled system designed for interior and exterior installation, combining design and technology in a single component. Features a stainless steel inner pipe and a load-bearing, powder-coated steel outer jacket.

TO CONTACT & ADVICE

Combination of technical functionality & architectural finish

Schiedel PERMETER is a double-walled chimney system engineered for standard heating appliances.

The inner pipe is manufactured from high-grade stainless steel (material grade 1.4521) with continuous butt-seam welding. The powder-coated steel outer jacket absorbs structural loads. The intervening space is filled with a specialized high-temperature Superwool insulation (25 mm standard or 50 mm optional). Individual elements join easily via a push-fit connection and are secured with included locking bands.

Quick Links

High-grade stainless steel inner liner

Manufactured with a continuous butt-welded stainless steel inner pipe (material 1.4521) to ensure operational reliability, acid resistance, and moisture insensitivity for oil and gas applications.

Manufactured with a continuous butt-welded stainless steel inner pipe (material 1.4521) to ensure operational reliability, acid resistance, and moisture insensitivity for oil and gas applications.

Specialized Superwool insulation

Pre-insulated with continuous 25 mm or 50 mm Superwool insulation. Maintains low outer surface temperatures and consistent internal thermal performance.

Pre-insulated with continuous 25 mm or 50 mm Superwool insulation. Maintains low outer surface temperatures and consistent internal thermal performance.

Structural powder-coated outer jacket

Load-bearing outer shell made of powder-coated steel, available in standard Matt Black, as well as Matt White or Matt Grey on special order.

Load-bearing outer shell made of powder-coated steel, available in standard Matt Black, as well as Matt White or Matt Grey on special order.

Simple & rapid installation

Precision-fitted elements with a simple push-fit connection secured by locking bands. Eliminates on-site welding and thermal insulation wrapping.

Precision-fitted elements with a simple push-fit connection secured by locking bands. Eliminates on-site welding and thermal insulation wrapping.

Gallery (Images & Videos)

Image Title: If somebody hovers the image it appears.
Image Title: If somebody hovers the image it appears.
